"callerNo": "+4672111111",
"start": "2017-01-04T16:16:04.274+01:00",
"receivingNo": "622",
"received": "2017-01-04T16:16:10.279+01:00",
"calleeNo": "+4672555555",
"calleeAnswered": "2017-01-04T16:16:10.279+01:00",
"stop": "2017-01-04T16:17:31.164+01:00"
},
{
"callerNo": "+4672222222",
"start": "2017-01-04T16:16:03.004+01:00",
"receivingNo": "711",
"received": "2017-01-04T16:16:10.279+01:00",
"calleeNo": "+4672777777",
"calleeAnswered": null,
"stop": "2017-01-04T16:16:33.578+01:00"
},
{
"callerNo": "+4672333333",
"start": "2017-01-04T16:16:03.004+01:00",
"receivingNo": "800",
"received": null,
"calleeNo": "+4672888888",
"calleeAnswered": null,
"stop": "2017-01-04T16:16:33.578+01:00"
}
]
callerNo | start | receivingNo | received |
From which number the call was made. | Date and time when the caller dialed the number and picked up the phone. | Which number first received the call. If this number is not empty, it is the number to a response group that can be 'ATTENDANT', 'ACD', 'ACD Light', or 'HUNT GROUP'. Note that, for example, 'IVR' (interactive voice response) is excluded. | When the call was received, date and time, otherwise the value 'null'. |
callerNo | callerAnswered | stop | |
Number to the first real person (user in the PBX) who received the call. | Date and time when the receiving person answered the call. If the call was not answered for some reason, the value is 'null'. | Date and time when the call ended. Note that the call is considered ended when the first person who received the call either hung up or transferred the call. |
If you want to retrieve call log for a certain period of time, you can use the parameters 'from' (= from and including) and 'to' (= up to and including). The search can, for example, be between two times on the same day or span several days.
Exemple:
https://api.dstny.se/cdr/historik?from=2017-01-04 08:00&to=2017-01-04 17:00
https://api.dstny.se/cdr/historik?from=2017-01-01 08:00&to=2017-01-04 17:00
https://api.dstny.se/cdr/historik?from=2017-01-04&to=2017-01-04
